Application Solutions

Here’s some interesting videos, pictures, facts and data report to show you NSW dispensing application solutions such as micro-volume dispensing technology (micro-dispensing), solder paste, phosphor, and adhesives dispensing.

Unlock New Era of Micro-dispensing/
Micro-DAM/Fine-dotting/Fine-line Dispensing

Embark on a New realm of miniaturization revolutions with NSW Micro dispensing technology! Experience unparalleled control and accuracy in micro-dispensing solutions, covering diverse applications from basic to heterogeneous, such as fine-line/fine-dots/Micro-DAM. Images below are overview of our micro-dispensing capabilities:

Micro-Lines
(Fine Streaks)

Micro-DAM with High-Standoff

Micro-Cavity Filling (Uneven Surface)

Which types of Industries We Served?

We offer a broad range of liquid dispensing systems suitable for mass production. Speed, repeatability, and consistency are imminent to us. Above all, our systems are also highly stable and accurate, which is critical for research and development of laboratory usage. Here are some ways that industries are finding our systems to be fitting for their production and manufacturing.

Semiconductor

NSW notable solder paste dispensing technologies are most suitable to solder MEMS devices and electronics micro components at micron-levels. Our systems can accurately perform microscopic wafer-level dispensing and other advanced semiconductor manufacturing dispensing processes such as flip chips, 3D packages, PoPs, and SiPs.

LED Industries

Phosphors are used in LEDs to produce visible light when exposed to radiation from an ultra-violet, deep blue, or electron beam source. Our dispensers would be able to dispense for LEDs to emit accurate desired colors and brightness.

SMT

Diverse major electronic component manufacturers highly used our dispensing systems in the Surface-Mount Technology (SMT) industry. It handles processes such as SMT hybrid assembly, 5G optical communication manufacturing. Our systems also cover 008004 SMD soldering, microscopic components assembly, and other microscopic SMT related processes.

Biotech & Medical

The latest S400 dispenser is popular among bioresearch industries, Our equipments fulfill the need for accuracy, preciseness, and stability in biotechnology. Besides research purposes, our dispensers can accurately dispense controlled amounts of liquid for lab and biology test kits.

EVs & Automotive

Our precision fluid dispensing systems are used for tire sensors, Car ECUs and pixel LEDs production. Our machine can dispense exact amounts of liquid consistently with good accuracy. Any inaccuracy could risk danger, risk, damage, or cause of injury towards the end-users vehicle.

Aerospace

NSW dispensing systems also solder sensitive compute equipment, MEMS devices, and sensors used in aircraft. it demands uniquity and customization to achieve outstanding accuracy. With customization and precision fluid dispensing capability, we can serve these unique demands.

Industrial Assembly

We have also made notable coverage in industrial assembly productions. Our system meets general and customized specifications to produce niched outputs. Some areas of coverage are sealing of gaps, bonding, encapsulation, gluing and microscopic pasting in watches.

Military

Military-grade cameras, drones, electronic are sensitive equipment. It's required to be faultless. Our high-precision dispensers deliver soldering pastes, adhesives, sealing compounds, and fluxing agents. It can also dispense oils, dyes, and solvents in whatever sophisticated microscopic designs to be combat-ready.

Solder Paste Micro Dispensing Application Demo Video Thumbnail

Precise like a Space Shuttle
Resolution Thinner than Hair
Size as Small as 80μm

NSW’s latest automated micro-volume solder paste dispensing systems are breakthrough techs. Our state-of-the-art microdispensing technology can execute challenging tasks such as 008004 (0.008” x 0.004) or smaller SMD soldering flawlessly.

Our liquid dispenser processes EMC phosphor casting and epoxy damming. Besides these, We also support advanced materials such as gallium and other materials such as die coating, adhesives, epoxy, and many more.

Similarly, Some manufacturing materials that our equipment able to support such as solder paste, phosphor, and adhesives. Moreover, we also support UV glue, TiO2, silver epoxy, silicone gel, high/low viscosity epoxies, and many more listed below.

Our microdispensing system has capabilities with superior consistency at every dispensation. It has successfully achieved the tiniest liquid dispensing dot diameter or line size of 40μm*, This is applicable for UV glue and 80μm* on T6 micro solder paste dispensing. These microscopic sizes are achievable with SD1, W12, S400 and A300 series of automated fluid dispensers.

We have collaborated with several major material manufacturers such as indium corporation. This allowed us to optimize their solder paste formulation to fit into our micro-dispensing equipment’s performance. Hence, we manage to achieve reliable fine volume dispensing results.

NSW microdispensing technology focuses on nanoscopic dispensing. This is an exceptional technology amongst the precision fluid dispensing market. Are you looking for dispenser solutions to dispense various types of controlled release materials? What if it can dispense the diminutive wafer-level size a hundred times smaller than the human hair? This is for you.

*Depending on material characteristics

Your Advanced Dispensing Solutions Partner

What Can We Dispense?
Micro Dispensing Application & Materials

We understand your needs. More manufacturers today are demanding for micron-level precision fluid dispensing systems. Therefore, we offer a broad range of solutions for your dispensing needs. From chemicals to semi-solid dispensing for the semiconductor, LED, and packaging industries, we strive to deliver highly innovative solutions always.

Materials That We Dispense:

  • Liquid Metal
  • Solder Paste (All types)
  • Phosphor
  • Conductive/non-conductive Adhesive
  • UV Glue/Adhesive
  • Titanium dioxide (TiO₂)
  • Silicone Gel
  • Silver Epoxy
  • Various types of chemical, epoxy or solvents
  • General liquid or semisolids
    (from low and very high viscosity)
  • Creams and paste
  • Others, Contact us for your special material

Manufacturing Processes with NSW Applications:

  • Micro-Damming (Micro-DAM)
  • Metaverse, Wearable Tech Assembly
  • 5G Module and Device Manufacturing
  • FPCB or PCB Dispensing
  • Micro Soldering (Solder paste Dispensing)
  • Flip-chip Packaging
  • Micro 3D SiP, SiP Packaging
  • 008004, 01005, 0201 SMD Soldering
  • Underfill Process
  • MEMs Dispensing
  • VCSEL Manufacturing
  • Chip on Board (COB) Process
  • CMOS Assembly
  • Glasses/Lens Edge Coating
  • EMC
  • Dam and Fill
  • Hot Melting
  • LED Encapsulation
  • EVs ECU & Module Assembly
  • Surface Mount Adhesive
  • Solder Paste Micro Bumping
  • Lid Attach Dispensing
  • Trench or Cavity Filling
  • Wafer Level Dispensing and Process
  • Die Coating
  • Coating or Sealing Process
  • Not listed? Contact us for your special request.
application-04

Solder Paste

application-03

Phosphor

Silicone Gel

Silicone Gel

Silver Epoxy

Silver Epoxy

UV Glue dispensing 80um

UV Glue

Underfill Dispensing

Underfill

Dam and fill

Dam and Fill

Independent Axis Dual-pump Dispensing

Ind. 2 Head Dispensing
